- Space saving – the smallest size is less than 1 meter square
- 70% of the footprint is passenger space.
- Machine is roomless and no pit needed
- Color: White (RAL 9016 GU-30 Matte)
- Can work with single phase electricity
- Can be installed in just 7-10 days
- A Cibes Uno platform lift with standard doors requires a headroom of only 2400 mm
- The EcoSilent drive system makes lift operation 45% more energy-efficient and is virtually soundless
- Comply with European Safety Standard Machinery Directive 2006/42/EC and also the local standards More than 200 different lift colors for you to choose
- Installation location: Indoor
- Load capacity: 400 kg
- Maximum number of stops: 6
- Maximum speed (m/s): 0.15m/s
- Travel height: 20m
- Min headroom: 2400mm
- Pit depth: 70mm – 0mm and install straight on the floor
- Drive system: Screw and nut
- Directives and standards: MD 2006/42/EC, EN 81-41
Popular Sizes
| Dimension | Platform size (mm) | Cut out size (mm) |
|---|---|---|
| 1 | 635x850 | 1070x940 |
| 2 | 935x1050 | 1370x1140 |
| 3 | 1035x1050 | 1470x1140 |
| 4 | 1135x1250 | 1570x1340 |
| 5 | 935x1450 | 1370x1540 |
DESIGN
White
