- Space saving – gain more standing space inside existing shafts than ever before
- As small as 1 sqm
- Machine roomless and no pit needed
- Can work with single phase electricity
- Can be installed in just 10 – 14 days
- Automatic saloon doors standard
- Tinted glass doors as standard
- Up to 0.25 m/s
- Anti-slip slate flooring from Forbo
- Full Touchscreen LCD, Touch call button
- Music, integrated fan, password lock and more!
-
Installation location: Indoor/Outdoor
-
Load capacity: 350kg/ (2-4 people) and 450kg/ (5-7 people)
-
Maximum number of stops: 6
-
Maximum speed (m/s): 0.15 - 0.25 m/s
-
Travel height: 20m
-
Min head room: 2500mm
-
Pit depth: 0mm/100mm
-
Machine room:Integrated (MRL)
TOUCHSCREEN PERFECTION
- Video back screen display – can be changed to custom user choices
- Ambient music linked to Bose sound system – can be changed to custom user choices
- Light control from touchscreen
- Fan control directly from touchscreen
- Child lock / passcode as standard
- Statistics, language, settings easily accessible through touchscreen
- Customizable floor names
- Open / Close Door functionalities
Popular Sizes
| Dimension | Cabin size (mm) | Cut out size (mm) |
|---|---|---|
| 1 | 710x815mm | 1090x960mm |
| 2 | 1110x915mm | 1490x1060mm |
| 3 | 1210x1215mm | 1590x1360mm |
| 4 | 1110x1415mm | 1490x1560mm |
Light Wood
Dark Wood
Imperial Marble
Celestial
Glacier
Relleaqua
Venetian
Amaranta
Chataigne
Azure
Ebene
Creme
Ivoire
Midnight Black
Lava
Jet Black
Golden Sunshine
Cedar Brown
A Champagne
Silver Sky
Sand Dune
Pearl River
Walnut Fresco
Titan Shale
Peat
Loam Shale
Colbalt Grey
Saloon door
